Products Description

Cradle type positioner is a highly versatile and efficient equipment used for positioning heavy loads, primarily used in welding and assembly processes. It is an advanced solution that improves work efficiency and productivity, reduces labor costs and enhances worker safety.

The product is a type of equipment used in welding and assembly applications. It consists of a base, cradle, and rotating mechanism that allows the workpiece to be positioned at different angles for welding, assembly, and other processes. The positioner is generally made of heavy-duty steel and has a weight capacity ranging from a few hundred kilograms to several tons. It is available in different sizes, with varying lengths and widths of the cradle to accommodate different sizes of workpieces.

Technical Specification

Item	Specification
Weight capacity	Ranging from a few hundred kilograms to several tons
Rotation speed	Typically, the rotation speed ranges from 0.1 to 2 revolutions per minute (RPM)
Rotation angle	The positioner can rotate the workpiece at angles ranging from 0 to 360 degrees
Control system	The control system can be operated manually or through a computerized interface
Power source	The positioner requires a power supply of 220V or 380V AC, depending on the model

Applications

Cradle type positioner is widely used in many industrial applications, including:

1. Welding: The positioner is ideal for welding large, heavy workpieces, providing precise control over the workpiece's positioning, resulting in high-quality welds.

2. Assembly: The product can be used for assembling large and complex products, reducing the need for manual labor and improving efficiency.

3. Painting: The positioner can be used for painting large workpieces, ensuring that every part of the workpiece is coated evenly.

4. Inspection: The product is ideal for inspecting large workpieces, providing a 360-degree view of the workpiece and improving inspection accuracy.

Technical Advantages

Cradle Type Positioner offers several advantages to users, making it an indispensable tool in many industrial applications:

1. Improved productivity: significantly improve productivity by reducing the time it takes to position a workpiece for welding. By rotating the workpiece in a controlled manner, welders can access all sides of the workpiece without having to stop and reposition it manually.

2. Precise positioning: rotate a workpiece to a precise angle or orientation, which is especially useful in applications where accuracy is critical. This precise positioning can also help ensure consistent weld quality.

3. Reduced operator fatigue: By using the products, operators can avoid physically rotating the workpiece themselves, which can be tiring and potentially lead to injury. This can reduce operator fatigue and increase safety.

4. Increased safety: improve safety by reducing the need for operators to manually handle heavy workpieces. This can help prevent injuries and accidents in the workplace.

5. Flexibility: available in a range of sizes and configurations, making them suitable for a variety of workpiece sizes and shapes. This flexibility can help increase the versatility of a welding operation.
